ESP32-S3 1.85inch Round Capacitive Touch LCD Development Board, 360×360, Supports Wi-Fi & Bluetooth BLE 5, AI Speech [Sound Box & Battery Not Included]

ESP32-S3 1.85inch Round Capacitive Touch LCD Development Board, 360×360, Supports Wi-Fi & Bluetooth BLE 5 & AI Speech [Sound Box & Battery Not Included]

ESP32-S3-Touch-LCD-1.85C is a microcontroller development board with 2.4GHz Wi-Fi and Bluetooth BLE 5 support, integrates high-capacity Flash and PSRAM. Onboard 1.85inch LCD display which can smoothly run GUI programs such as LVGL. Combined with various peripheral interfaces, it is suitable for the quick development of the HMI and AI, voice, and wireless communication projects.

User Manual / Datasheet / Example Codes Etc.

Features

• Equipped with high-performance Xtensa 32-bit LX7 dual-core processor, up to 240MHz main frequency
• Supports 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth 5 (LE), with onboard antenna
• Built-in 512KB SRAM and 384KB ROM, with onboard 16MB Flash and 8MB PSRAM
• Onboard 1.85inch LCD display, 360×360 resolution, 262K color
• Supports capacitive touch controlled via I2C interface, with interrupt support
• Adapting UART, I2C and some IO interfaces
• Onboard audio decoder, Microphone, RTC sensor, TF card slot and battery recharge management module, etc.
• Supports accurate control such as flexible clock and multiple power modes to realize low power consumption in different scenarios

Specifications

• Display: 1.85-inch round
• Display Type: IPS
• Resolution: 360 × 360 pixels
• Touch: Capacitive multi-touch panel
• Core Chip: ESP32-S3 – Dual-core Xtensa® LX7 CPU

Package Includes

• ESP32-S3-Touch-LCD-1.85C x1
• SH1.0 4PIN cable ~100mm ×2
• 8Ω 2W speaker ×1

Excellent Display Performance

262K color, 360×360 resolution, wide viewing angle

Supports multiple peripherals

Supports the expansion of multiple peripherals via UART, I2C and GPIO interfaces, etc.

What's On Board

Dimensions
