Name: MAX7219CNG - LED Matrix/ 8 Digit Display Driver
Brand: Multicomp
SKU: 01208
Price: 151.04 INR
Availability: InStock

MAX7219CNG - LED Matrix/ 8 Digit Display Driver

Multicomp

MAX7219CNG - LED Matrix/ 8 Digit Display Driver

Based on 0 reviews. - Write a review

₹151.04

₹128.00 + 18% GST

All Inclusive, Shipping Calculated at Checkout

B2B GST Credit Available

Stock: 46 in Stock
SKU: 01208
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

MAX7219CNG - Serially Interfaced LED Matrix/ 8 Digit Display Driver - MAXIM INTEGRATED - 24PDIP

The MAX7219 does all the control and refresh work for you in driving either an 8x8 matrix display or 8 x 7-segment displays (usually these also have a dot so its really an 8-segment display) - 64 LEDs total. All you have to do is send it serial commands via the 4-pin SPI interface and it will auto-magically take care of the rest. Wiring is simplified as well, you only need to set the current level for all LEDs with a single resistor instead of 8 and you can also dim the entire display digitally. It's a thru-hole chip so you can use it in any breadboard, perfboard or other project, although if you're soldering it in, we suggest using a socket.

Technical Datasheet (456 KB)

MAX7219 and 8x8 LED Matrices Tutorial on ARDUINO Playground.

Arduino Library LEDControl for 7-Segment and LED Matrix Control using MAX72xx
