Name: Ebyte E22-900MM22S SX1262 868~915MHz 22dBm Ultra Small Size LoRa Module SMD
Brand: Ebyte
SKU: 06183
Price: 413.00 INR
Availability: InStock

Ebyte E22-900MM22S SX1262 868~915MHz 22dBm Ultra Small Size LoRa Module SMD

Ebyte

Ebyte E22-900MM22S SX1262 868~915MHz 22dBm Ultra Small Size LoRa Module SMD

Based on 0 reviews. - Write a review

₹413.00

₹350.00 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 3
B2B GST Credit Available

Price in reward points: 350

Stock: 1 in Stock
SKU: 06183
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

Ebyte E22-900MM22S SX1262 868~915MHz 22dBm Ultra Small Size LoRa Module SMD

E22-900MM22S is based on the new generation of LoRaTM radio frequency chip SX1262 produced by Semtech in the United States as the core of the independent research and development of ultra-small volume, and is suitable for 868MHz, 915MHz chip LoRaTM wireless module.

Datasheet

Features

The measured communication distance can reach 7km.
Maximum transmit power 160mW, multi-stage tunable software
supports global license-free ISM 868/915MHz band
LoRaTM supports data transfer rates ranging from 0.018 to 62.5kbps.
FSK mode supports up to 300kpbs data transfer rate.
Backwards compatible with SX1278/SX1276 series RF transceivers
The FIFO has a large capacity and supports 256Byte data caching.
A new SF5 spreading factor that supports dense networks.
supports 1.8V to 3.7V power supply, and any power supply greater than 3.3V ensures the best performance.
Industrial-grade standard design, supporting long-term use at -40 ~ 85°C
IPEX interface, stamp hole optional, easy to user secondary development, easy to integrate.

Specifications

Chip solution: SX1262
Working frequency band: 850MHz～930MHz
Transmission power: 22dBm
Communication distance: 7km
Communication interface: SPI
Antenna interface: Stamp hole/IPEX
Operating temperature: -40 to 85°C
Working temperature: -40 to 85°C
Product size: 10*10*2.5mm

Applications

Home security alarm and remote keyless entry
Smart home and industrial sensors, etc.
wireless alarm security system
Building automation solutions
Wireless industrial-grade remote control
Advanced Meter Reading Architecture (AMI)
Applications in the automotive industry.
