DWIN 7inch TN TFT LCD, No Touch, TN TFT 800x480 450nit LCD Display, LN80480T070ID4598
₹​1,156.00
₹​979.66 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 10
B2B GST Credit Available
Price in reward points: 980

DWIN 7inch TN TFT LCD, No Touch, TN TFT 800x480 450nit LCD Display, LN80480T070ID4598

The DWIN 7inch TN TFT LCD display, a compact yet powerful solution for your visualization needs. Engineered with precision and reliability in mind, this display offers a crisp and clear viewing experience suitable for a wide range of applications.


Datasheet


Features

  •  7.0 inch, 800×480 pixels, TN-TFT-LCD
  • 16.7M color, 450 cd/m², RGB_24bit interface
  • OEM A-grade glass, no bad pixels, full inspection, 30 days charged aging process


Specifications

  • Color: 16.7M
  • LCD Type: TN-TFT-LCD
  • Viewing Angle: Normal viewing angle, 70/70/50/70(L/R/U/D)
  • Display Area(A.A): 154.08(W)*85.92(H)
  • Driver IC: EK9713CA+EK73002AB2/ILI6122+ILI5960
  • Luminance: 450cd/m²
  • LED Numbers: 27 LEDS
  • Interface: RGB_24bit 50PIN_0.5mm


Electrical Characteristics

  • Digital Power Voltage: 3.3V(Typ.)
  • Forward Voltage: 9.3V(Typ.)
  • Forward Current: 180mA
  • LED Life-Time: 20000 Hr


Optical Characteristics

  • Contrast Ratio: 500:1
  • Response Time: ON:10ms  OFF:15ms
  • Uniformity: 75%
