DWIN 8inch TN TFT LCD, No Touch, TN TFT 800x600 900nit High Brightness LCD Display, LN80600T080IA9098
The DWIN 8inch TN TFT LCD display, a compact yet powerful solution for your visualization needs. Engineered with precision and reliability in mind, this display offers a crisp and clear viewing experience suitable for a wide range of applications.
Features
- 8.0 inch, 800*600 pixels resolution, TN-TFT-LCD
- 16.7M color, RGB_24bit interface, 900 cd/m²
- OEM A-grade glass, no bad pixels, full inspection, 30 days charged aging process
Specifications
- Color: 16.7M
- LCD Type: TN-TFT-LCD
- Viewing Angle: Normal viewing angle, 70/70/50/70(L/R/U/D)
- Display Area(A.A): 162.0(W)*121.5(H)
- Driver IC: HX8264-E00DPD400/HX8677-A000PD400-A
- Luminance: 900cd/m²
- LED Numbers: 27 LEDS
- Interface : RGB_24bit 50PIN_0.5mm
Electrical Characteristics
- Forward Voltage: 9.3V(Typ.)
- Forward Current: 405mA
- LED Life-Time: 25000Hr
Optical Characteristics
- Contrast Ratio: 500:1
- Response Time: 35~50ms
- NTSC: 55%
- Luminance Uniformity: 75%
