This product is a 64 × 32 RGB LED matrix panel, with 2048 RGB LEDs onboard, 4mm pitch, supports Raspberry Pi and Arduino, etc. It provides supporting open-source demos and tutorials, suitable for makers or electronics Enthusiasts to start learning, or DIY secondary development into other desktop or wall-mounted display applications.
Features
- 2048 individual RGB LEDs, full-color display, adjustable brightness
- 64×32 pixels, 4mm pitch, allows displaying text, colorful image, or animation
- 256×128mm dimensions, moderate size, suitable for DIY desktop display or wall mount display
- Onboard two HUB75 header, one for controller data input, one for output, chain support
- Provides open source development resources and tutorials, for use with Raspberry Pi, Arduino, and so on
Resources

Specifications
| DIMENSIONS | 256mm × 128mm |
|---|---|
| PIXELS | 64×32=2048 DOTS |
| PITCH | 4mm |
| PIXEL FORM | 1R1G1B |
| VIEWING ANGLE | ≥160° |
| CONTROL TYPE | synchronization |
| DRIVING | 1/16 scan |
| HEADER | HUB75 |
| POWER SUPPLY | 5V / 4A (VH4 header input) |
| POWER | ≤20W |
