RP2040 MCU Board, With 0.99inch Round LCD, Accelerometer And Gyroscope Sensor, With CNC Metal Case

RP2040-LCD-0.99-B is a low-cost, high-performance MCU board designed by Waveshare. Tiny size with onboard 0.99inch LCD round display (with flat bottom), 6-axis sensor (3-axis accelerometer and 3-axis gyroscope) and so on, adapting 4 × GPIO pins through SH1.0 6PIN connector, which makes it easy for you to develop and integrate it into products quickly.

User Manual / Datasheet / Example Codes Etc.

Features

RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom
Dual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz
264KB of SRAM, and 2MB of on-board Flash memory
Type-C connector, keeps it up to date, easier to use
Onboard 0.99inch 128×115 pixels 65K colorful IPS LCD display (with flat bottom) for clear color pictures
4 × GPIO pins are adapted through SH1.0 6PIN connector
Adopts CNC metal case with Acrylic dull-polish bottom plate
USB 1.1 with device and host support
Low-power sleep and dormant modes
Drag-and-drop programming using mass storage over USB
2 × I2C, 4 × 12-bit ADC
Accurate clock and timer on-chip
Temperature sensor
Accelerated floating-point libraries on-chip
8 × Programmable I/O (PIO) state machines for custom peripheral support

Package Includes

RP2040-LCD-0.99-B x1
SH1.0 6PIN cable x1

CNC Metal Case

What's On Board

1. USB Type-C connector

for programming, USB 1.1 with device and host support

2. RT9013-33GB

500mA low dropout, low noise, ultra-fast LDO

3. QMI8658C

IMU, includes a 3-axis gyroscope and a 3-axis accelerometer

4. W25Q16JVUXIQ

2MB NOR-Flash

5. RP2040

Dual-core processor, up to 133MHz operating frequency

6. SH1.0 6PIN connector

Adapting 4 × GPIO pins, the pin order is: GND, 3V3, GP26~GP29

7. BOOT Button

press it when powering on to enter download mode

Dimensions
