Long-wave IR Thermal Imaging Camera HAT (B) For Raspberry Pi, 45° FOV, 80×62 Pixels, Standard 40PIN GPIO Header, Raspberry Pi IR Camera

This is a long-wave IR thermal imaging camera HAT that adopts the hybrid technology of microbolometer and thermopile pixel, features 80x62 array pixels. It will detect the IR distribution of objects in the field of view, turn the data into the surface temperature of the objects by calculation, and then generate thermal images, for easy integration into miscellaneous industrial or intelligent control applications.

Compared to the Thermal Camera HAT, this product features optimized internal filter and image processing algorithm, reducing the lens size to 9 × 9 mm and using FPC cable for connecting. The product provides basic version and wide angle version with 45° FOV.

User Manual / Datasheet / Example Codes Etc.

Features

Adopts the hybrid technology of microbolometer and thermopile, 80x62 array pixels
Continuous operation and thermal imaging video stream due to shutterless design
Calibrated each pixel to ensure uniformity and accuracy of temperature reading
Noise Equivalent Temperature Difference (NETD) 150mK RMS@1Hz refresh rate
Up to 25FPS (Max) thermal imaging video stream output
Basic version 45° FOV
Comes with online resources and manuals (Python demo for Raspberry Pi, Android/Windows host computer and user manual, etc.)

Specifications

Power supply: 5V
Operating current: 61mA@5V
wavelength range: 8~14μm
Operating temperature: -40~85℃
Target temperature: -40~400℃
Refresh rate: 25 FPS (Max)
Field of view (FOV): 56°(D) × 45°(H) × 34°(V)
Noise Equivalent Temperature Difference: 125mK
Measuring Accuracy: ±1.5℃ (ambient temp. 10~70℃)
Dimensions: 65.0mm × 30.5mm

Applications

Long-term non-contact temperature online monitoring
IR thermal imaging devices, IR thermometers
Smart home, intelligent building, intelligent lighting
Infant and elderly care
Fever detection
Industrial temperature control, security & safety, intrude/motion detection
Small Target Thermal Analysis, Heat Trend Analysis and Solutions

Package Includes

1x Thermal-45 Camera HAT (B)
1x 2 × 20 PIN female header
1x Screws pack

Application Scenarios

Onboard 40PIN GPIO Header

Compatible with Raspberry Pi boards

for reference only, the Raspberry Pi boards above are NOT included

Dimensions
