Long-wave IR Thermal Imaging Camera Module With 80×62 Pixels, 90°FOV, Type-C Female Port

This is a long-wave IR thermal imaging camera that adopts the hybrid technology of microbolometer and thermopile pixel, features 80x62 array pixels. It will detect the IR distribution of objects in the field of view, turn the data into surface temperature of the objects by calculation, and then generate thermal images, for easy integration into miscellaneous industrial or intelligent control applications.

User Manual / Datasheet / Example Codes Etc.

Features

Adopts the hybrid technology of microbolometer and thermopile, 80x62 array pixels
Continuous operation and thermal imaging video stream due to shutterless design
Noise Equivalent Temperature Difference (NETD) 150mK RMS@1Hz refresh rate
Up to 25FPS (Max) thermal imaging video stream output
Comes with online resources and manuals (Python demo for Raspberry Pi, Android/Windows host computer and user manual, etc.)

Specifications

POWER SUPPLY : 5V
OPERATING CURRENT : 61mA@5V
WAVELENGTH RANGE : 8~14μm
OPERATING TEMPERATURE : -20~85℃
TARGET TEMPERATURE : -20~400℃
REFRESH RATE : 25 FPS (Max)
FOV : 45°(H)×45°(V)
NOISE EQUIVALENT TEMPERATURE DIFFERENCE : 150mK
MEASURING ACCTRACY : ±2℃ (ambient temp. 10~70℃)
DIMENSIONS : Thermal Camera HAT: 65.0×30.5mm
Thermal USB Camera: 62.0×13.0mm

Applications

High precision long-term non-contact temperature online monitoring
IR thermal imaging devices, IR thermometers
Smart home, intelligent building, intelligent lighting
Industrial temperature control, security & safety, intrude/motion detection
Small Target Thermal Analysis, Heat Trend Analysis and Solutions

Thermal USB Camera

Onboard Type-C connector

Package Includes

Application Scenarios

Dimensions
