Name: Rail-mount TTL To RS422 Galvanic isolated Converter, Anti-surge, Multiple Isolation Protection
Brand: WaveShare Electronics
SKU: 23652
Price: 1020.00 INR
Availability: OutOfStock

Rail-mount TTL To RS422 Galvanic isolated Converter, Anti-surge, Multiple Isolation Protection

WaveShare Electronics

Rail-mount TTL To RS422 Galvanic isolated Converter, Anti-surge, Multiple Isolation Protection

Based on 0 reviews. - Write a review

₹1,020.00

₹864.41 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 9
B2B GST Credit Available

Price in reward points: 865

Stock: 0 in Stock
SKU: 23652
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

TTL TO RS422 (B) is an industrial-grade rail-mounted electrically isolated TTL-to-RS485 serial converter.

Features

Compatible with TTL/RS422 standard, converting the TTL signal into differential RS422 signal, support full duplex communication
Compatible with 3.3V ~ 5V TTL signal level, provides anti-reverse and over-voltage protection for power supply interface
Onboard unibody power supply isolation, provides stable isolated voltage and needs no extra power supply for the isolated terminal
Onboard unibody digital isolation, allows signal isolation, high reliability, strong anti-interference, low power consumption
Onboard TVS (Transient Voltage Suppressor), effectively suppresses surge voltage and transient spike voltage in the circuit, anti-electrostatic
Onboard resettable fuse and protection diodes, ensures the current/voltage stable outputs, provide over-current/over-voltage protection, improve shock resistance
Onboard RS422 input and output terminal 120R resistor, enabled/disabled via jumper
Industrial rail-mount ABS case design, small in size, easy to install, and cost-effective

Resources

User Guide

Specifications

PRODUCT TYPE	Galvanic isolated TTL to RS422 converter
POWER SUPPLY INTERFACE	Power supply	3.3V ~ 5V
POWER SUPPLY INTERFACE	Protection	over-voltage, reverse-proof
DEVICE PORT	TTL/RS422 standard compatible
TTL	Connector	screw terminal
	Transmission distance	about 10m
	Transmission mode	point-to-point
RS422	Connector	screw terminal
	Protection	surge-suppress and 15KV ESD protection
	Terminal resistor	120R, enabled/disabled via jumper (inside the case)
	Transmission Distance	About 1.2km
	Transmission Mode	full duplex mode, point-to-multipoint (up to 256 nodes, it is recommended to use repeaters for 16 nodes or more)
APPEARANCE	Case	Rail-mount ABS case, suitable for 35mm DIN rail
APPEARANCE	Dimensions	106.0 × 58.6 × 36.0mm

Interface

Applications
