USB C PD/QC High Speed Charger Power Delivery Boost Module with Screw Terminal - DC 5V~20V Adjustable Voltage
The Type-C PD QC Trigger DC 5V~20V Adjustable Voltage Power Module is a versatile and compact tool designed for electronics enthusiasts and professionals alike. This module allows you to harness the power of USB Type-C Power Delivery (PD) and Quick Charge (QC) protocols, enabling you to adjust and output voltages from 5V to 20V. With support for fast charge protocols like PD 3.0, PD 2.0, QC 2.0/3.0, and BC1.2, it ensures that your devices charge quickly and efficiently.
Whether you’re working on DIY projects, charging batteries, or developing and testing electronic devices, this module offers the flexibility and control you need. It features a user-friendly interface for easy voltage selection and built-in protection against over-voltage, over-current, and short-circuit conditions, ensuring safe and reliable operation.
Features
- The PD decoy supports PD3.0/2.0, BC1.2 and other boost and fast charging protocols.
- supports up to 10w power, and provides over-temperature, over-voltage protection and other functions.
- The voltage can be adjusted by the dial switch, and the maximum output voltage is 20V.
- Support fast charging protocols such as PD3.0/2.0 and BC1.2
- Supports USB Type-C PD, forward and reverse insertion detection and automatic switching
- Support 4V to 22V input voltage
Specifications
- Input Voltage: DC 4V-22V (via USB Type-C)
- Output Voltage: Adjustable from 5V to 20V
- Interface: support USB Type-C PD
- Power: up to 100W
- Supported Protocols: PD 3.0, PD 2.0, QC 2.0/3.0, BC1.2
- Dimensions: 11*25.7mm
Instructions For Use
- CFG1 corresponding dial switch 1
- CFG2 corresponding dial switch 2
- CFG3 corresponds to dial switch 3
- Dial down to 1, and dial up to 0.
- Toggle the switch to request the corresponding voltage according to the charger protocol
Package Includes
- 1x USB C PD/QC High Speed Charger Power Delivery Boost Module with Screw Terminal
