Name: USR-M100 Remote IO Gateway Module 2DO/2DI/2AI Expandable IO
Brand: USR IoT
SKU: 04897
Price: 7899.00 INR
Availability: InStock

USR-M100 Remote IO Gateway Module 2DO/2DI/2AI Expandable IO

USR IoT

USR-M100 Remote IO Gateway Module 2DO/2DI/2AI Expandable IO

This product qualifies for Free Surface Shipping !

All orders with value above 1999+GST are eligible for free delivery in Surface mode. (Not applicable for B2B offline orders)

Based on 0 reviews. - Write a review

₹7,899.00

₹6,694.07 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 67
B2B GST Credit Available

Price in reward points: 6694

Stock: 11 in Stock
SKU: 04897
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

USR-M100 Remote IO Gateway Module 2DO/2DI/2AI Expandable IO

The USR-M100 is an intelligent IoT I/O gateway with comprehensive functions like on-board I/O support and RS-485/232/Ethernet interface, is an advanced modular RTU product with a unique hardware and software design, making it an ideal solution for a variety of industrial data acquisition applications. The USR-M100 has a unique mechanical design that reduces the amount of time required for installation and removal, simplifying deployment and maintenance. In addition, the USR-M100 supports Modbus RTU Master protocol for retrieving field site serial data from serial meters and also supports OT/IT protocol conversion.

Resource

Features

High-performance CPU processing ability,using 32-bit Arm Cortex-M7 core CPU, up to 400MHz frequency
Provides remote serial access over the Internet for industrial serial devices
10/100Mbps Ethernet port and support Auto MDI/MDIX
Built-in 15KV ESD serial port protection
Supports a wide industrial operating temperature,-40℃~85℃
Baud rate: 0.6~230.4 Kbps, and any baud rate setting, support None, Odd, Even, Mark, Space Parity bit
Flexible serial port data framing packing, which can satisfy user’s various demands for data packets segmentation
Versatile operation modes: TCP Server, TCP Client, UDP, HTTP client, Websocket server
Support virtual COM USR-VCOM(windows)
Modbus Ethernet-to-Serial support (Modbus/TCP, Modbus/RTU) for seamless integration of serial Modbus devices
Provides rich configuration access, including: Windows configuration tool, and Web Browser
Firmware upgrading via Web Browser and Windows configuration tool
High security via certificate verification SSL/TLS encryption for serial data transmission,HTTPS,TCPS,MQTTS
Support modbus RTU master,edge computing, modbus gateway,MQTT gateway
Support SNMP V1/V2c
Support on board I/O for analog input(2 AI), digital input(2 DI), digital output(SSR relay,2 DO), expandable with I/O modules, digital out support linkage control
Support 2 RS485 serial port, the first one can also be RS232
Cloud support: MQTT via AWS IOT, Microsoft Azure, Thingsboard, Alibaba Cloud, EMQX,
Tuya,Cumulocity IoT and so on
