XH-M543 TPA3116D2 120Wx2 Dual Channel Class D Digital Power Amplifier Board

The XH-M543 TPA3116D2 Dual Channel 120W Digital Power Amplifier Board is a newly designed, high-performance amplifier board that combines ease of use with superior audio quality. Leveraging the latest TPA3116D2 Dual Channel technology, this board delivers up to 120W of powerful stereo output, making it ideal for building or upgrading your own music system. The high-efficiency Class D amplifier design ensures minimal distortion and maximum efficiency, while the advanced BTL (Bridge-Tied Load) circuit enhances performance, providing clean and robust sound. This module offers a practical and effective solution for creating high-quality audio systems with significant power and clarity.

Features

Strong TPA3116D2 chip is a digital power amplifier chip, with low idle loss characteristics, makes it work well and quickly.
Onboard, front-facing IC to improve the input sensitivity, high-definition sound quality.
It can be used for car vehicle computer speaker, family audio and video, and empty square.
This product has the characteristics of loud sound, the capacitance is large, excellent sound quality.
There is no solder joint on the back of the circuit board, the chip capacitors and the solder board together, so there is no possibility of short circuit.

Specifications

Name: TPA3116D2 Digital Amplifier Board
Model: XH-M543
Chip type: TPA3116D2
Working voltage: DC12-26V
Output power: 120*2W MAX, DC12V, 2*50W,DC24V, 2*120W
Signal to noise ratio: 100db
Channel: Dual channel stereo
Size: 92 x 68 x 16mm

Package Includes

1x XH-M543 TPA3116D2 120Wx2 Dual Channel Class D Digital Power Amplifier Board

Connection Diagram
