DWIN 4.3inch Resistive Touch Panel, 4 wire Touch Panel, YF04303
This is a DWIN 4.3inch Resistive Touch Panel, 4 wire Touch Panel, YF04303. The Dwin 4.3inch Touch Panel Comes With ITO Film+ITO Glass+FPC Structure, Which Support 3H Surface Hardness and Operation Temperature -20℃~70℃.
Features
- 4.3 inch, 4 wire resistive touch panel
- Structure: ITO film+ITO glass+FPC
- Light touch, no drift, no calibration and high stability
- Cutomized service: high temperature, high humidity and anti-UV
Specifications
- Structure : ITO Film+ITO Glass+FPC
- Glass Dimensional Outline : 67.70(L)×106.00(W)×1.55(T)
- Active Area : 56.16(L)×93.60(W)
- Operation Temperature : -20℃~70℃
- Storage Temperature : -30℃~80℃
- Humidity : 20℅~90℅ non dew condensation
- Surface Hardness : 3H
- Transmittance : 78%±3%
- Life : Dot >1000000; Stroke >100000
- Rated Voltage : ≤5V
- Terminal Impedance : X: 100-450Ω, Y: 400-1100Ω
- Linearity : X direction: within ±1.5℅, Y direction: within ±1.5℅
- Insulation Resistance : DC 25V 20MΩ above
CAD
