Ex Gst ₹93.22₹708.00
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 2
B2B GST Credit Available
Price in reward points: 204
- Stock: 47 in Stock
- SKU: 04262
- Delivery Time
- Bulk & B2B RFQ
DWIN 7inch Resistive Touch Panel, 4 wire Touch Panel, YF07002
This is a DWIN 7inch Resistive Touch Panel, 4 wire Touch Panel, YF07002. The Dwin 7inch Touch Panel Comes With ITO Film+ITO Glass+FPC Structure, Which Support 3H Surface Hardness and Operation Temperature -20℃~70℃.
Features
- 7 inch, 4 wire resistive touch panel
- Structure: ITO film+ITO glass+FPC
- Light touch, no drift, no calibration and high stability
- Customized service: high temperature, high humidity and anti-UV etc
Specifications
- Structure : ITO Film+ITO Glass+FPC
- Glass Dimensional Outline 163.8(L)×97.8(W)×1.5(T)
- Active Area : 153.68(L)×86.18(W）
- Operation Temperature : -20℃~70℃
- Storage Temperature : -30℃~80℃
- Surface Hardness : 3H
- Transmittance : 78%±3%
- Life : Dot >1000000; Stroke >100000
- Rated Voltage : ≤5V
- Terminal Impedance : X: 400-1100Ω, Y: 100-450Ω
- Linearity : X direction: within ±1.5℅, Y direction: within ±1.5℅
- Insulation Resistance : DC 25V 20MΩ above
CAD
