1.47inch LCD Display Module With Touch Panel, Micro LCD Display, 172×320 Resolution, IPS, SPI And I2C Communication, 262K Display Color

This 1.47-inch LCD Display Module combines a compact form factor with rich visual output and touch interaction, making it ideal for embedded and portable applications. Featuring a vibrant 172×320 resolution IPS panel, this micro LCD delivers wide viewing angles, crisp visuals, and smooth touch functionality. It supports both SPI and I2C communication interfaces for flexible integration with various microcontrollers and development boards.

User Manual / Datasheet / Example Codes Etc.

Features

172×320 resolution, 262K colors, clear and colorful displaying effect
High touch screen transmittance, fast response and long lifetime
Embedded JD9853 driver chip and AXS5106L capacitive touch control chip, using SPI and I2C communication respectively, minimizes required IO pins, supports controller boards like Raspberry Pi / ESP32S3 / Raspberry Pi Pico / Arduino
Comes with online development resources and manual (examples for Raspberry Pi / ESP32S3 / Raspberry Pi Pico / Arduino)

Specifications

Display Size: 1.47inch
DISPLAY PANEL: IPS
Touch Type: Capacitive
Resolution: 172 × 320 pixels
Operating voltage: 3.3V / 5V
Display Driver: JD9853
Touch Driver: AXS5106L
Display Interface: 4-wire SPI
Touch Interface: I2C
Display size: 17.75 × 32.93mm
Module size: 22.05 × 41.69mm

Package Includes

1.47inch Touch LCD x1
SH1.0 13PIN cable ~100mm x1
FFC cable x1

Dimensions
