OV7670 Camera Module without FIFO - VGA - 30 FPS
₹293.82
All Inclusive, Shipping Calculated at Checkout
B2B GST Credit Available
- Stock: 18 in Stock
- SKU: 01235
- Delivery Time
- Bulk & B2B RFQ
OV7670 Camera Module without FIFO - VGA - 30 FPS
OV7670 Sensor Datasheet by Omnivision
OV7670 Information (HTTP)
A nice Tutorial on Interfacing this Camera Module with STM32 Microcontroller (HTTP)
The camera module comes with a 9x2 header, the pin diagram is shown below:
| VDD | GND |
| SDIOC | SDIOD |
| VSYNC | HREF |
| PCLK | XCLK |
| D7 | D6 |
| D5 | D4 |
| D3 | D2 |
| D1 | D0 |
| RESET | PWDN |
| Pin | Type | Description |
|---|---|---|
| VDD** | Supply | Power supply |
| GND | Supply | Ground level |
| SDIOC | Input | SCCB clock |
| SDIOD | Input/Output | SCCB data |
| VSYNC | Output | Vertical synchronization |
| HREF | Output | Horizontal synchronization |
| PCLK | Output | Pixel clock |
| XCLK | Input | System clock |
| D0-D7 | Output | Video parallel output |
| RESET | Input | Reset (Active low) |
| PWDN | Input | Power down (Active high) |
