ATTINY2313A-PU - TinyAVR - 2 KB Flash - DIP20 - 20 MHz
The high-performance Atmel picoPower AVR RISC-based CMOS 8-bit microcontroller combines 2KB flash memory, 128B EEPROM, 128B SRAM, 18 general purpose I/O lines, 32 general purpose working registers, a single-wire Interface for on-chip debugging, two flexible timer/counters with compare modes, internal and external interrupts,serial programmable USART, a universal serial interface (USI) with start condition detector, programmable watchdog timer with internal oscillator, and three software selectable power saving modes. The device operates between 18.8-5.5 volts. By executing powerful instructions in a single clock cycle, the device achieves throughputs approaching 1 MIPS per MHz, balancing power consumption and processing speed.
| Flash [KBytes] | 2 |
| Pin Count | 20 |
| Device Package | Plastic Dual In Line |
| Max Operating Frequency | 20MHz |
| CPU | 8-bit AVR |
| Hardware QTouch Aquisition | No |
| Max IO Pins | 18 |
| External Interrupts | 18 |
| USB function | NA |
| ADC | Yes, |
| SPI | 1 Channel |
| I2C/ TWI | 1 Channel |
| UART | 1 Channel |
| Analog Comparator | 1 |
