4inch Raspberry Pi LCD - 320×240 - IPS Screen - Resistive Touch - Plug and Play

This product qualifies for Free Surface Shipping !

All orders with value above 1999+GST are eligible for free delivery in Surface mode. (Not applicable for B2B offline orders)
₹​3,020.80
₹​2,560.00 + 18% GST
All Inclusive, Shipping Calculated at Checkout

B2B GST Credit Available

4inch Raspberry Pi LCD - 320×480 - IPS Screen - Resistive Touch - Plug and Play


4 inch resistive touch screen TFT LCD designed to work directly with Raspberry Pi, Raspbian Image is provided in a DVD with this product. A Touch pen is also included for effective touch interface. IPS technology enabled screen performs better in terms of viewing angle and overall better perception of visual content.


Features -

  • Designed specifically for Raspberry Pi, Plug and Play working, Ideal alternative to HDMI LCDs
  • Comes with a printed user manual for quick start
  • Works flawlessly with any revision of Raspberry Pi
  • Supports Raspbian/ Ubuntu
  • IPS (In-Plane Switching) technology for high quality visual experience with wide viewing angle.
  • Enables your system to take photos by touch, supports 17 different camera modes
  • Supports on screen key board, it makes a stand alone system, no need of any external keyboard or mouse
  • High quality design with immersion gold pcb surface plating.

 Technical Specifications

LCD TypeTFT
LCD InterfaceSPI
Touch screen typeResistive
Touch screen controllerXPT2046
Colors65536
BacklightLED
Resolution320 x 480 Pixels
Aspect Ratio8:5
















Pin description

PIN NO.SYMBOLDESCRIPTION
1, 173.3VPower positive (3.3V power input)
2, 45VPower positive (5V power input)
3, 5, 7, 8, 10, 22NCNC
6, 9, 14, 20, 25GNDGround
11TP_IRQTouch Panel interrupt, low level while the Touch Panel detects touching
12KEY1Key
13RSTReset
15LCD_RSLCD instruction control, Instruction/Data Register selection
16KEY2Key
18KEY3Key
19LCD_SI / TP_SISPI data input of LCD/Touch Panel
21TP_SOSPI data output of Touch Panel
23LCD_SCK / TP_SCKSPI clock of LCD/Touch Panel
24LCD_CSLCD chip selection, low active
26TP_CSTouch Panel chip selection, low active






Development Resources

Visit product Wiki page for development related resources at http://www.waveshare.com/wiki/4inch_RPi_LCD_(A)


External Dimensions
