2.66inch E-Paper E-Ink Display Module for Raspberry Pi Pico, 296×152, Black / White, SPI
2.66inch EPD (Electronic Paper Display) Module For Raspberry Pi Pico, 296 × 152 Pixels, Black / White, SPI Interface.
This is an Active Matrix Electrophoretic Display (AM EPD), with interfaceand a reference system design. The display is capable to display images at 1-bit white, black and redfull display capabilities. The 2.66 inch active area contains 296×152 pixels. The module is aTFT-array driving electrophoresis display, with integrated circuits including gate driver, sourcedriver, MCU interface, timing controller, oscillator, DC-DC, SRAM, LUT, VCOM. Module can beused in portable electronic devices, such as Electronic Shelf Label (ESL) System
User Manual / Datasheet / Example Codes Etc.
Features
- 296×152pixels display
- High contrast High reflectance
- Ultra wide viewing angle Ultra low power consumption
- Pure reflective mode
- Bi-stable display
- Commercial temperature range
- Landscape portrait modes
- Hard-coat antiglare display surface
- Ultra Low current deep sleep mode
- On chip display RAM
- Waveform can stored in On-chip OTP or written by MCU
- Serial peripheral interface available
- On-chip oscillator
- On-chip booster and regulator control for generating VCOM, Gate and Source driving voltage
- I2C signal master interface to read external temperature sensor
- Built-in temperature sensor
Specifications
- Size: 2.66 inch
- Outline dimensions (screen only): 71.820mm × 36.304mm × 1.05mm
- Outline dimensions (driver board): 74.0mm × 37.5mm
- Display size: 60.088mm × 30.704mm
- Operating voltage: 3.3V
- Communication interface: SPI
- Pixel pitch: 0.202 × 0.203
- Resolution: 296 × 152
- Display color: Black, White
- Grey scale: 2
- Partial refresh: 0.3s
- Full refresh: 6s
- Refresh power: 42.4mW (typ.)
- Sleep current: <0.01uA (almost 0)
Package Includes
- 1x Pico-ePaper-2.66
- 1x Standoff pack
Raspberry Pi Pico Header Compatibility
Pinout Definition
