2.9inch E-Paper (B) E-Ink Raw Display, 296×128, Red / Black / White, SPI, without PCB

2.9inch E-Paper (B) E-Ink Raw Display, 296×128, Red / Black / White, SPI, without PCB

The display is a TFT active matrix electrophoretic display, with interface and a reference system design. The 2.9” active area contains 296×128 pixels, and has 1-bit white/black and 1-bit red full display capabilities. An integrated circuit contains gate buffer, source buffer, interface, timing control logic, oscillator, DC-DC, SRAM, LUT, VCOM, and border are supplied with each panel.

User Manual / Datasheet / Example Codes Etc.

Features

•   High contrast
•  High reflectance
•  Ultra wide viewing angle
•  Ultra low power consumption
•  Pure reflective mode
•  Bi-stable
•  Commercial temperature range
•  Landscape, portrait mode
•  Antiglare hard-coated front-surface
•  Low current deep sleep mode
•  On chip display RAM
•  Waveform stored in On-chip OTP
•  Serial peripheral interface available
•  On-chip oscillator
•  On-chip booster and regulator control for generating VCOM, Gate and source driving voltage
•  I2C Signal Master Interface to read external temperature sensor
•  Available in COG package IC thickness 280um

Specifications

Dimensions
