3.5inch Capacitive Touch Display Module, 320×480 Resolution, Embedded with ST7796S Display Driver and FT6336U Capacitive Touch Controller, IPS Display

The 3.5-inch Capacitive Touch Display Module is a versatile and reliable display solution designed for modern embedded applications. It features a 320×480 resolution, delivering sharp and clear visuals, and utilizes IPS technology to provide vibrant colors and wide viewing angles.

Equipped with the ST7796S display driver, this module ensures seamless integration and stable performance. The FT6336U capacitive touch controller enables precise and responsive touch input, making it suitable for interactive interfaces.

User Manual / Datasheet / Example Codes Etc.

Features

320×480 resolution, 262K colors, clear and colorful displaying effect
High touch screen transmittance, fast response and long lifetime
Embedded with ST7796S driver chip and FT6336U capacitive touch control chip, using SPI and I2C communication respectively, minimizes required IO pins
Onboard TF card slot for storing more pictures, videos, music, etc.
Adapting 15PIN connector and 18PIN FPC slot for connecting the LCD module to the host board
Onboard voltage translator, compatible with 3.3V / 5V operating voltage
Comes with online development resources and manual (examples for Raspberry Pi / ESP32 / Raspberry Pi Pico / Arduino)

Specifications

Operating Voltage: 3.3V / 5V
Display Driver: ST7796S
Display Interface: 4-wire SPI
Display Panel: IPS
Pixel Pitch: 0.051 × 0.153 (mm)
Display Size: 48.96 × 73.44 (mm)
Resolution: 320 × 480 pixels
Touch Driver: FT6336U
Touch Interface: I2C
Touch Type: Capacitive
Touch Points: Two-point touch
Module Size: 61.00 × 92.44 (mm)

Package Includes

3.5inch Capacitive Touch LCD x1
GH1.25 15Pin cable x1

SPI and I2C Control Interfaces

Options For 15PIN Connector Or 18PIN FPC Slot For Connecting The LCD To The Host Board

Dimensions
