5V Single Channel Relay Module - Low Level Trigger
The 5V Single Channel Relay Module (Low Level Trigger) is a compact and reliable switching device designed for controlling high-voltage or high-current loads using low-voltage control signals. It operates on a 5V DC supply and uses a low-level trigger, making it compatible with most microcontrollers such as Arduino, ESP8266, ESP32, Raspberry Pi, and other logic-level devices.
This module features an onboard relay capable of switching AC loads up to 250V/10A or DC loads up to 30V/10A, making it suitable for automation, DIY electronics, home appliances control, and industrial projects. The module also includes an indicator LED for trigger status and an optocoupler (in many versions) for enhanced isolation and safe operation. With its screw-terminal output and simple 3-pin control interface (VCC, GND, IN), the module offers easy integration and reliable performance for a wide range of switching applications.
Specfications
- Operating Voltage: 5V DC
- Trigger Type: Low-level trigger
- Relay Type: SPDT (Single Pole Double Throw)
- Maximum Load (AC): 250V AC @ 10A
- Maximum Load (DC): 30V DC @ 10A
- Control Signal Current: Approx. 5–15 mA
- Relay Coil Current: ~70 mA
- Isolation: Optocoupler (varies by model)
- Input Pins: VCC, GND, IN
- Output Terminals: COM, NO, NC
- Indicator LED: Power and relay status
