6inch 800x600 E-Ink display HAT for Raspberry Pi, IT8951 controller, USB/SPI/I80/I2C interface

6inch 800x600 E-Ink display HAT for Raspberry Pi, IT8951 controller, USB/SPI/I80/I2C interface
WaveShare Electronics
6inch 800x600 E-Ink display HAT for Raspberry Pi, IT8951 controller, USB/SPI/I80/I2C interface
₹​6,202.08
₹​5,256.00 + 18% GST
All Inclusive, Shipping Calculated at Checkout

B2B GST Credit Available

800x600, 6inch E-Ink display HAT for Raspberry Pi, IT8951 controller, USB/SPI/I80/I2C interface

This is an E-Ink display HAT for Raspberry Pi, 6inch, 800x600 resolution, with embedded controller IT8951, communicating via USB/SPI/I80/I2C interface, supports partial refresh. Due to the advantages like ultra low power consumption, wide viewing angle, clear display without electricity, it is an ideal choice for applications such as shelf label, industrial instrument, and so on.


Package Contains:

  • → 6inch e-Paper x1
  • → e-Paper IT8951 Driver HAT x1
  • → 6inch e-Paper Adapter x1
  • → 33PIN FFC (same side contact) x1
  • → USB type A plug to micro B plug cable x1
  • → PH2.0 20cm 8Pin x1
  • → RPi screws pack (2pcs) x1

Features:

  • → No backlight, keeps displaying last content for a long time even when power down
  • → Low power consumption, basically power is only required for refreshing
  • → Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards
  • → USB/SPI/I80/I2C interface, for connecting with host boards like Raspberry Pi/Nucleo, etc.
  • → Comes with development resources and manual (examples for Raspberry Pi/STM32)

Technical Specifications:

  • → Operating voltage: 5V
  • → Interface: USB/SPI/I80/I2C
  • → Outline dimension: 138.4mm × 101.8mm × 0.954mm
  • → Display size: 122.4mm × 90.6mm
  • → Dot pitch: 0.153mm × 0.151mm
  • → Resolution: 800 × 600
  • → Display color: black, white
  • → Gray scale: 2-16 (1-4 bit)
  • → Full refresh time: <1s
  • → Total refresh power: 0.6W(typ.)
  • → Total standby power: 0.3W(typ.)
  • → Viewing angle: >170°




Resources:

www.waveshare.com/wiki/6inch_e-Paper_HAT


6inch e-Paper HAT e-Paper IT8951 Driver HAT dimensions
