9745P Electret Condenser Microphone

9745P Electret Condenser Microphone

The 9745P Electret Condenser Microphone is a high-performance microphone component, designed for applications requiring clear and sensitive audio capture. Known for its reliability, this microphone is well-suited for consumer electronics, communication devices, and industrial applications. It leverages electret condenser technology to provide accurate sound reproduction in compact form, making it a versatile choice for various devices.

Specifications

• Sensitivity: -48---66dB (0dB=1v/Pa100OHz)
• Frequency range:50---2OKHz
• Directivity: omnidirectional
• Impedance: low impedance
• Current consumption: Maximum 50OuA
• Standard operation voltage: 3V
• operation voltage range: 1.5-10V
• S/N ratio: ＞ 58dB
• Sensitivity reduction: Voltage change 1.5V sensitivity change less than 3dB
• Dimensions: 9.7*4.5mm

Package Includes

• 1x 9745P Waterproof Electret Condenser Microphone
