A7672S is the LTE Cat 1 module that supports wireless communication modes of LTE-FDD/GSM/GPRS/EDGE . A7672S supports maximum 10Mbps downlink rate and 5Mbps uplink rate. A7672S adopts LCC+LGA form factor and is compatible with SIM7000/SIM7070 series (NB/Cat M modules), and SIM800A/SIM800F series (2G modules), which enables smooth migration from 2G/NB/Cat M products to LTE Cat 1 products, and greatly facilitates more compatible product design for the customer needs.

Datasheet

Features

• LTE-FDD B1/B3/B5/B8
• LTE-TDD B34/B38/B39/B40/B41
• GSM/GPRS/EDGE 900/1800 MHz
• GNSS & BLE (Bluetooth) Support
• Supply Voltage : 3.4V - 4.2V, Typ: 3.8V
• Operation temperature : -40°C - +85°C
• Dimensions : 24mm x 24mm x 2.4m

Data Transfer LTE Cat 1

• Uplink up to 5Mbps
• Downlink up to10Mbps
• EDGE Uplink/Downlink up to 236.8Kbps
• GPRS Uplink/Downlink up to 85.6Kbps

Other Features

• USB Driver for Microsoft Windows 7/8/10
• USB Driver for Linux /Android
• RIL supporting for Android 5.0/6.0/7.0/8.0/9.0
• Firmware update via USB/FOTA TCP/IP/IPV4/IPV6/Multi-PDP/FTP/HTTP/DNS
• RNDIS/PPP/ECM
• MQTT/MQTTS
• TLS1.2
• LBS

Interfaces

• USB2.0
• UART
• (U)SIM card(1.8V/3V )
• Analog audio
• ADC
• I2C
• GPIO
• Antenna: Primary/GNSS/BT
