CAPUF Industrial Grade Isolated USB to UART Converter

The CAPUF Embedded Industrial Grade Isolated USB to UART Converter is a high-performance device designed to facilitate seamless communication between USB interfaces and UART-enabled devices. This converter is ideal for industrial applications requiring robust and reliable data transfer with electrical isolation to protect sensitive equipment.

This is mainly useful for companies/engineers who are involved in building power electronics products or dealing with high-voltage DC or AC signals on their board and want to connect their board to the laptop.

Resource

Features & Specs

Onboard USB to UART Chip CH340C
USB-C Port
USB to UART Bridge capable of up to 3Mbps
Isolated Power, capable of up to 100mA. Short Circuit Protected.
Isolated RX, TX, RTS, CTS, DTR, DSR, and all IOs are ESD-protected.
Signal voltage level selection 1.8/2.5/3.3/5V via DIP Switch
A 2-pin Jumper is provided to select if you want to power the target(Jumper ON) or if it will be self-powered.
LED Indication for RX, TX, & Power
A male 8-pin header (angled) comes in the package but is unsoldered.
Compact Size: 30.5mm x 70.5mm

Block Diagram
