This is an industrial expansion module based on Raspberry Pi CM4, which features common interfaces such as Gigabit Ethernet, HDMI, USB, and GPIO, allowing additional 4G / 5G / LoRa wireless communication modules to be connected via the M.2 or Mini-PCIe socket. There are also industrial interfaces/resources including RS485, CAN, and RTC.

Combined with the industrial rail-mount protection case, the module is an ideal choice for building an IoT gateway, 4G/5G router, IoT data acquisition, or even the PLC device in the industrial automatic control system, and more.

Resources

User Manual

Specifications

CM4 Socket	suitable for all variants of Compute Module 4
Networking	Dual Gigabit Ethernet RJ45; M.2 B KEY / Mini-PCIe (via adapter), for connecting 5G / 4G / LoRa wireless module; Nano-SIM card slot supports standard Nano-SIM card for 5G/4G/3G/2G communication
USB	USB 2.0 x 3
PIN Header	Non-isolated RS485 × 2, Non-isolated CAN × 1, Partial GPIO pins
Camera	MIPI CSI-2 × 1 (15pin 1.0mm FPC connector)
Video	HDMI × 1, supports 4K 30fps output
RTC	Real-time clock with a battery socket and ability to wake Compute Module 4
Storage	MicroSD card socket for Compute Module 4 Lite (without eMMC) variants
Fan Header	5V/12V allows speed adjustment and measurement
Power input	5V or 7~36V

Connecting With Compute Module 4

Standard CM4 Socket And Partial Raspberry Pi GPIO Header Suitable For Compute Module 4 Lite/EMMC Series Module

4G/5G/LoRa Wireless Modules Support

Onboard M.2 Slot, Comes With Mini-PCIe Adapter As Well, Compatible With 4G/5G/LoRa Wireless Modules With M.2 Or Mini-PCIe Interface

Rich Interfaces

Providing Interfaces Including: CSI / HDMI / USB / ETH / CAN / RS485 / M.2 B KEY

Reserved Space For Heat Dissipation

NOTE: for reference ONLY, the heatsink and cooling fan are NOT included.

Rail-Mount Support

Rail-Mount ABS Protection Case, Easy To Install, More Safe Operation

Application Example

Suitable For IoT Gateway, 4G/5G Router, IoT Data Acquisition And Monitoring, Industrial PLC, Or Other Industrial Applications

NOTE: For reference only, CM4, displays are NOT included.

Package Includes

CM4-IO-WIRELESS-BASE x1
PCIe to 4G/LoRa adapter x1
Screwdriver x1
Screws pack x1
4G module
SIM7600G-H-PCIE
PCB antenna IPEX connector
12V 2A power adapter
