Name: Waveshare Jetson TX2 NX Development Kit, Deep Learning and Edge Computing, (4GB RAM+ 16GB EMMC)
Brand: WaveShare Electronics
SKU: 23036
Price: 44958.00 INR
Availability: OutOfStock

Waveshare Jetson TX2 NX Development Kit, Deep Learning and Edge Computing, (4GB RAM+ 16GB EMMC)

WaveShare Electronics

Waveshare Jetson TX2 NX Development Kit, Deep Learning and Edge Computing, (4GB RAM+ 16GB EMMC)

This product qualifies for Free Surface Shipping !

All orders with value above 1999+GST are eligible for free delivery in Surface mode. (Not applicable for B2B offline orders)

Based on 0 reviews. - Write a review

₹44,958.00

₹38,100.00 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 381
B2B GST Credit Available

Price in reward points: 38100

Stock: 0 in Stock
SKU: 23036
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

Waveshare Jetson TX2 NX Development Kit, Deep Learning and Edge Computing (Based On NVIDIA Jetson TX2 NX Module)

NVIDIA Jetson TX2 NX delivers next-generation AI performance for entry-level embedded and edge products. It is s small and low-power, which makes it ideal for your next AI solution for manufacturing, transfer learning, the retail industry, agriculture, and life sciences. Pre-trained AI models, transfer learning toolkits, and the NVIDIA JetPack SDK help you bring powerful products to market quickly.

This kit includes a TX2 NX Module with onboard 16GB eMMC, does not support Micro SD card.

User Manual / Datasheet / Example Codes Etc.

Jetson TX2 NX Specifications

GPU: NVIDIA Pascal architecture with 256 NVIDIA CUDA® cores
CPU: Combination of dual-core NVIDIA Denver 2 64-bit CPU and quad-core Arm Cortex-A57 MPCore processor
Memory: 4 GB 128-bit LPDDR4 51.2 GB/sec
Storage: 16 GB eMMC 5.1 Flash / M.2 M KEY NVME SSD Interface
Video Encoding: 3 x 4K30 | 4 x 1080p60 | 8 x 1080p30 (H.265) - 1 x 4K60 | 3 x 4K30 | 7 x 1080p60 | 14 x 1080p30 (H.264)
Video Decoding: 4 x 4p30 | 7 x 1080p60 | 14 x 1080p30 (H.265 and H.264)
Camera: Up to 5 cameras (support up to 12 via virtual channels) - 12-Ch MIPI CSI-2 (3 x 4 or 5 x 2) - D-PHY 1.2 (up to 30 Gbps)
Networking: Wi-Fi requires an external chip - 10/100/1000 BASE-T Ethernet
Display: 2 x Multimode DP 1.2/eDP 1.4/HDMI 2.0 - 1 x 2 DSI (1.5Gbps/channel)
UPHY: 1 x 1 (PCIe Gen3) + 1 x 4 (PCIe Gen4), 1 x USB 3.0, 2 x USB 2.0
IO: 3 x UART, 2 x SPI, 2 x I2S, 4 x I2C, multiple GPIO headers

Package Includes

1x Waveshare TX2 NX development kit:
1x Jetson TX2 NX Module
1x JETSON-IO-BASE-B
1x Cooling Fan
1x 128GB NVMe SSD
1x Wireless network card
1x Power adapter
1x Ethernet cable (~1.5m)

Based On NVIDIA Jetson TX2 NX Module

JETSON TX2 NX DEV KIT Onboard Resources

Jetson TX2 NX Module
40PIN GPIO Headers
Micro USB Interface: For USB data transmission
Gigabit Ethernet Port: 10/100/1000Base-T self-adaptive Ethernet port
4-Ch USB 3.0 port
HDMI Interface
DisplayPort Interface
DC Power Port: For 9~19V power input
2-Ch MIPI CSI Camera Port
Fan Header
