Luckfox Core3576 Edge Computing Development Board, Based On Rockchip RK3576 Octa-Core 2.2GHz Processor, Features A big.LITTLE Architecture, 6 TOPS Computing Power NPU, 4GB Ram & 32GB eMMC

Luckfox Core3576 Edge Computing Development Board, Based On Rockchip RK3576 Octa-Core 2.2GHz Processor, Features A big.LITTLE Architecture, 6 TOPS Computing Power NPU, 4GB Ram & 32GB eMMC

The Luckfox Omni3576 main control unit utilizes the Rockchip RK3576 processor, which is built on an advanced 8nm process technology. It features an octa-core 64-bit CPU (including 4×[email protected] and 4×[email protected]), an integrated ARM Mali-G52 MC3 GPU, and a built-in NPU with a performance of 6 TOPS. It supports various video input and output interfaces, offering strong computing and graphics processing capabilities, with support for 8GB of large memory, 2.4/5G Wi-Fi, and 4G wireless communication. It boasts rich interface expansions suitable for a wide range of applications, including IoT devices, smart audio, smart displays, industrial control, and educational equipment. The Luckfox Omni3576 supports Buildroot, Debian 12, Android 14, and Ubuntu 22.04 systems.

User Manual / Datasheet / Example Codes Etc.

Specifications

• Processor: Quad-core Arm [email protected] + Quad-core Arm [email protected]
• RAM: 4GB LPDDR4X RAM
• EMMC: 32GB eMMC Flash
• NPU: 6 TOPS@INT8, supports INT4, INT8, INT16, FP16, BF16, TF32 mixed operation
• GPU: ARM Mali G52 [email protected], supports OpenGL ES 1.1/2.0/3.2, OpenCL 2.0 and Vulkan 1.1, built-in high-performance 2D/3D acceleration hardware
• ISP: Built-in 16MP ISP, supports multiple algorithm accelerators such as HDR, 3A, CAC, 3DNR, 2DNR, Sharpening, Dehaze, Enhance, Debayer, and small-angle lens distortion correction, etc.
• Video: Decoding: 4K@120fps (H.265/HEVC, VP9, AVS2, AV1); 4K@60fps (H.264/AVC), Encoding: 4K@60fps (H.265/HEVC, H.264/AVC)
• Storage: TF card slot M.2 connector × 1 (PCIe NVMe SSD support, compatible with 2242/2260/2280 size)
• Connectivity: 1000M Ethernet port × 2, Onboard wireless module supporting 2.4GHz/5GHz dual-band Wi-Fi6 and Bluetooth 5.2/BLE
• Video Output: HDMI2.1 (4K@120fps) port × 1 & 4-lane MIPI DSI (2K@60fps) interface × 1
• Video Input: 4-lane MIPI CSI camera interface × 2
• USB: USB Type-C (5Gbps/DP) × 1, supports OTG and image burning & USB3.2 Gen1 port (5Gbps) × 1 & USB2.0 port × 3
• CAN Supports high-speed CAN FD and CAN2.0A/B data communication.
• Audio: Onboard microphone 3Pin MX1.25 audio output header
• GPIO: 40Pin GPIO header (compatible with most Raspberry Pi HATs)
• System Support: Buildroot, Debian, Ubuntu, Android 14
• Power input: 5V DC
• Ambient temperature

• Operating temperature: 0°C ~ 60°C
• Storage temperature: 0°C ~ 70°C
• Storage humidity: 10% ~ 90%RH (no condensation)

• Others
• Onboard IR receiver with 38KHz carrier frequency
• 2Pin SH1.0 RTC battery header
• 5V fan header

Package Includes

• 1x Core3576 Edge Computing Development Board (including Core3576 Module) (4GB + 32GB)

What's on board

Dimensions
