DWIN 2.8inch Resistive Touch Panel, TN TFT 240x320 250nit COF Touch screen Model, COF Series, DMG32240F028_02WTR
This is a DWIN 2.8inch Resistive Touch Panel, TN TFT 240x320 250nit COF Touch screen Model, COF Series, DMG32240F028_02WTR. The 2.8inch Resistive Touch Panel Based on T5L0, running DGUS II system, Which Comes 2.8 inch, 240*320 pixels resolution, 262K colors, TN TFT display.
Features
- Based on T5L0, running DGUS II system.
- 2.8 inch, 240*320 pixels resolution, 262K colors, TN TFT display.
- LCD and TP frame lamination process, only 3.75mm thickness.
- COF structure. The entire core circuit of the smart screen is integrated on the FPC of LCM, featured by light and thin structure, low cost and easy production.
- 50 pins, including IO, UART, CAN, AD and PWM from user CPU core for easy secondary development.
- T5L0 ASIC : T5L0 ASIC is a low-power, cost-effective, GUI and application highly integrated single-chip dual-core ASIC designed by DWIN Technology for small-size LCD and mass produced in 2020.
Display
- Color : 262K colors
- LCD Type : TN, TFT LCD
- Viewing Angle : Normal viewing angle, typical value of 70°/70°/40°/30°(L/R/U/D)
- Display Area（A.A) : 43.2mm(W)×57.6mm(H)
- Resolution : 240*320
- Backlight : LED
- Brightness : DMG32240F028_02WTR:250nit
Interface
- User interface : 50Pin_0.5mm FPC
- Baudrate : 3150~3225600bps
- Output Voltage : Output 1;3.0~3.3 V / Output 0;0~0.3 V
- Input Voltage（RXD) : Input 1；3.3V / Input 0；0~0.5V
- Interface : UART2: TTL; / UART4: TTL;（Only available after OS configuration / UART5: TTL;（Only available after OS configuration）
- Data Format : UART2: N81; / UART4: N81/E81/O81/N82;4 modes (OS configuration) / UART5: N81/E81/O81/N82;4 modes (OS configuration)
Voltage & Current
- Power Voltage : 3.6~5.5V
- Operation Current : 110mA VCC=5V, max backlight / 50mA VCC=5V, backlight off
Reliability Test
- Working Temperature : -10℃~60℃
- Storage Temperature : -20℃~70℃
- Working Humidity : 10%~90%RH, typical value of 60% RH
