DWIN 4.3inch TFT LCD, Resistive Touch, RGB 18bit TFT 480x272 250nit Intelligent LCD Display, DMG48270C043_04WTR
This is a DWIN 4.3inch TFT LCD, Resistive Touch, RGB 18bit TFT 480x272 250nit Intelligent LCD Display, DMG48270C043_04WTR. The Dwin 4.3inch Resistive touch comes with 16.7millon RGB 18bit colors, Which Based on self-designed T5L0.
Features
- Based on self-designed T5L0, 16.7M Color, 18bit, 480*272, Cheap TV-TN-TFT-LCD
- Resistive touch screen
- 232 Interface,10Pin1.0mm FCC connection wire
- Download via SD card or on-line serial port
- Easy-to-use DWIN DGUS V7.624 GUIs Development, no coding skills required
- Dual Development System: DGUS II/ TA(Instruction set)
- Cost-Effective TN screen
Display
- Color : 18-bit 6R6G6B
- LCD Type : TV-TN, TFT LCD
- Viewing Angle : TV viewing angle, 70°/70°/40°/30° (L/R/U/D)
- Display Area（A.A) : 95.04mm (W) ×53.86mm (H)
- Resolution : 480×272
- Backlight : LED
- Brightness : DMG48270C043_04WTR: 230nit
Electrical specifications
- Rated Power : <5W
- Working Voltage : 4.5~5.5V, typical value of 5V
- Working Current : VCC = +5V, Backlight on,180mA / VCC = +5V, Backlight off,60mA
Interface
- LCM interface : FPC40_0.5mm, RGB interface
- RTP interface : FPC4_1.0mm
- Baudrate : 3150~3225600bps
- Output Voltage : Output 1, Iout =-4mA 2.7~3.2 / Output 0, Iout = 4mA 0.1~0.4
- Input Voltage（RXD）: Input 1， Iin = 1mA；2.4-5.5V / Input 0， Iin = -1mA；0~1.0V
- Interface : UART2: N81 / UART4: N81/E81/O81/N82 4 modes (OS configuration)
- User Interface : 10Pin_1.0mm latching socket for power supply and serial communication. Download rate(typical value): 12KByte/s
- Flash : 16MBytes NOR Flash, for fonts, pictures and audio files. Rewrite cycle: over 100,000 times
- Buzzer : 3V passive buzzer. Power: <1W
- SD interface : FAT32. Download files by SD interface can be displayed in statistics. Download rate: 4Mb/s
- PGT05 interface : When product crashes by accident, you can use PGT05 to update DGUS kernel and make the product return to normal
Touch Parameters
- Type : RTP (Resistive touch panel)
- Structure : ITO film + ITO glass
- Touch Mode : Support point touch and drag
- Surface Hardness : 3H
- Light Transmittance : Over 80%
- Life : Over 1,000,000 times touch
Voltage & Current
- Power Voltage : 4.5~5.5V
- Operation Current : VCC = +5V, Backlight on,190mA (RTP/No touch), 200mA (CTP) / VCC = +5V, Backlight off, 70mA
Reliability Test
- Working Temperature : -20℃~70℃
- Storage Temperature : -30℃~80℃
- Working Humidity : 10%~90%RH
