All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 15
B2B GST Credit Available
Price in reward points: 1497
- Stock: 0 in Stock
- SKU: 04314
- Delivery Time
- Bulk & B2B RFQ
DWIN 4.3inch HMI TFT LCD, Resistive Touch, TV-TN TFT 480x272 250nit LCD Display With Case, DMG48270C043_15WTR
This is a DWIN 4.3inch HMI TFT LCD, Resistive Touch, TV-TN TFT 480x272 250nit LCD Display With Case, DMG48270C043_15WTR. The 4.3inch Resistive Touch display comes with 262k colors with resistive touch, 250nit brightness.
Features
- 480*272 resolution, 262K colors
- Resistive touch screen
- RS232 and RS485 Interface, 8Pin2.0mm connection wire
- Download via SD card or on-line serial port
- 8MBytes NOR Flash, for fonts, pictures and audio files
- Brightness is up to 250nit
Specifications
- Color : 262K colors
- LCD Type : TV-TN, TFT LCD
- Viewing Angle : TV viewing angle, 70°/70°/40°/30°（L/R/U/D）
- Display Area（A.A）: 95.00mm (W) ×53.90mm (H)
- Resolution : 480x272
- Backlight : LED
- Brightness : 250nit
Touch parameters
- Type : RTP (Resistive touch panel)
- Structure : ITO film+ITO glass
- Touch Mode : Single touch and continuous sliding touch supported
- Surface Hardness : 3H
- Light Transmittance : Over 80%
- Life : Over 1,000,000 times touch
Voltage & Current
- Power Voltage : 6~36V
- Operation Current : VCC = 12V, Max backlight,109mA - VCC = 12V, Backlight off,50mA
Reliability Test
- Working Temperature : -20~70℃
- Storage Temperature : -30~80℃
- Conformal coating : No
Interface
- LCM interface : FPC40_0.5mm, RGB interface
- RTP interface : 4Pin_1.0mm interface
- Baudrate : UART2:3150~3225600bps - UART4:3150~921600bps
- Output Voltage : UART2: Output 1; -5.0~-3.0 V / Output 0; 3.0~5.0 V - UART4: Output 1; 2.5~5.0 V / Output 0; -0.5~-2.5 V
- Input Voltage（RXD） UART2: Input 1; -15.0~-5.0 V / Input 0; 5.0~15.0 V - UART4: Input 1; 0~2.5V / Input 0; -2.5~-0.2 V
- Interface UART : 2:RS232,N81 - UART4: RS485,N81/E81/O81/N82,4 modes (OS configuration)
- User Interface : 8Pin_2.0mm socket for power supply and serial communication. Download rate(typical value): 12KByte/s
- Flash : 8MBytes NOR Flash, for fonts, pictures and audio files. Rewrite cycle: over 100,000 times
- Buzzer : 3V passive buzzer. Power: <1W
- SD interface : FAT32. Download files by SD interface can be displayed in statistics
- PGT05 interface : When product crashes by accident, you can use PGT05 to update DGUS kernel and make the product return to normal
