DWIN 4 Inch HMI LCD, Resistive Touch, IPS TFT 480x800 300nit UART LCD Display, DMG80480C040_03WTR (Commercial Grade)
This is an DWIN 4 Inch HMI LCD, Resistive Touch, IPS TFT 480x800 300nit UART LCD Display. The Dwin 4inch HMI LCD comes with Resistive Touch, 480x800 resolution, 300nit brightness & 16.7M colors, Which Based on T5L1, running DGUS II system
Features
- Based on T5L1, running DGUS II system, commercial grade
- Resistive touch,16.7M Colors,24bit,480×800 pixel;
- UART2: N81; UART4: N81/E81/O81/N82;10Pin_1.0mm
- Download via SD card or on-line serial port
- Easy-to-use DWIN DGUS V7.624 tool to make GUI
- Dual Development System: DGUS II/ TA(Instruction set)
- IPS View Angle: 85°/85°/85°/85° (L/R/U/D)
- With GUI & OS dual-core, GUI with rich controls,support self-designed customized products based on T5L.
Specifications
Display Information
- Color : 16.7M（16777216） colors
- LCD Type : IPS, TFT LCD
- IPS Viewing Angle : 85°/85°/85°/85° (L/R/U/D)
- Display Area（A.A） : 51.8mm (W) ×86.4mm (H)
- Resolution : 480x800
Operating Environment
- Working Temperature : -20℃~70℃
- Storage Temperature : -30℃~80℃
- Working Humidity : 10%~90%RH
- Power Voltage : 4.5~5.5V
- Operation Current : VCC=5V，, Backlight on,200mA, VCC=5V，, Backlight off,70mA
Touch Parameters
- Type : Resistive touch panel
- Structure : ITO film + ITO glass
- Touch Mode : Support point touch and drag
- Surface Hardness : 3H
- Light Transmittance : Over 80%
- Life : Over 1,000,000 times touch
Display Interface
- LCM interface : FPC40_0.5mm, RGB interface
- Baudrate : 3150~3225600bps
- Output Voltage : Output 1, Iout = 1mA;3.0~3.3 V, Output 0, Iout =-1mA;0~0.3 V
- Input Voltage（RXD : Input 1， Iin = 1mA；2.4~5.0V, Input 0， Iin = -1mA；0~0.5V
- Interface : UART2: TTL/CMOS, UART4: TTL/CMOS（Only available after OS configuration), 10Pin_1.0mm latching socket for power supply and serial communication. Download rate(typical value): 12KByte/s
- Flash : 16MBytes NOR Flash, for fonts, pictures and audio files. Rewrite cycle: over 100,000 times
- Buzzer : 3V passive buzzer. Power: <1W
- SD interface : FAT32. Download files by SD interface can be displayed in statistics. Download rate: 4Mb/s
- Reserved module interface : Wi-Fi module: connect to the cloud platform to update remotely, USB module: download files by USB flash disk
- PGT05 interface : When product crashes by accident, you can use PGT05 to update DGUS kernel and make the product return to normal
