₹2,749.00
All Inclusive, Shipping Calculated at Checkout
B2B GST Credit Available
- Stock: 83 in Stock
- SKU: 03158
- Delivery Time
- Bulk & B2B RFQ
This model is the intelligent LCD display module with a capacitive touch screen for user interactivity. It has onboard serial UART PORT which can be controlled by any microcontroller via a simple yet powerful command set. It can be used as TFT Display & Touch controller in various electronic equipment such as vending machines, currency counting machines, washing machines, and many other similar appliances.
Features:
- T5L0 ASIC , 16.7M Colors running DGUS II system, commercial grade.
- 5.0inch 800xRGBx480, 18bit Colors, UART Serial TFT LCD display module.
- Capacitive touch screen,G+G structure,support point touch and drag ;
- 10Pin1.0mm FCC connection wire, TTL Interface uart communication;
- Download files by SD interface can be displayed in statistics
- High standard TFT LCD ,IPS Panel. Viewing Angle is 85/85/85/85,
Resources:
Specifications:
| Model | DMG80480C050_04WTC |
| LCD Type | IPS TFT |
| Touch Panel | Capacitive Touch Panel |
| Resolution | 800*480 |
| Display Size | 5 inches |
| Brightness | 280nit |
| Interface | UART/TTL/CMOS |
| Operational Voltage | 4.5V to 5.5V |
| Typical Current | 70mA to 240mA |
| Dimensions | 143.5 x 80.9 x 15.8 (in mm) |
