DWIN 7inch TFT, Touch Panel, TN TFT 800x480 200nit COF Series LCD Display, DMG80480F070_02WTC
This is a DWIN 7inch TFT, Touch Panel, TN TFT 800x480 200nit COF Series LCD Display, DMG80480F070_02WTC. The Dwin 7inch Touch Display comes with 262k colors with 200nits, Which Based on T5L0, running DGUS II system.
Features
- Based on T5L0, running DGUS II system.
- 7 inch, 800*480 pixels resolution, 262K colors, TN TFT display
- LCD and TP frame lamination process.
- COF structure. The entire core circuit of the smart screen is fixed on the FPC of LCM, featured by light and thin structure, low cost and easy production.
- 50 pins, including IO, UART, CAN, AD and PWM from user CPU core for easy secondary development.
Specifications
Display
- Color 262K colors
- LCD Type TN, TFT LCD
- Viewing Angle TV viewing angel, typical value of 70°/70°/40°/30°(L/R/U/D)
- Display Area（A.A） 154.08mm (W)×85.92mm (H)
- Resolution 800*480
- Backlight LED
- Brightness DMG80480F070_02WTC:200nit
Volatage & Current
- Power Voltage : 4.5~5.5V, typical value of 5V
- Operation Current : 440mA VCC=5V, max backlight / 120mA VCC=5V, backlight off
Reliability Test
- Working Temperature : -10℃~60℃
- Storage Temperature : -20℃~70℃
- Working Humidity : 10%~90%RH, typical value of 60% RH
Interface
- User interface : 50Pin_0.5mm FPC
- Baudrate : 3150~3225600bps
- Output Voltage : Output 1;3.0~3.3 V / Output 0;0~0.3 V
- Input Voltage（RXD）: Input 1；3.3V Input 0；0~0.5V
- Interface : UART2: TTL; / UART4: TTL;（Only available after OS configuration / UART5: TTL;（Only available after OS configuration）
- Data Format : UART2: N81; / UART4: N81/E81/O81/N82;4 modes (OS configuration) / UART5: N81/E81/O81/N82;4 modes (OS configuration)
