DWIN 4.3inch IPS, Capacitive Touch, RGB, IPS 800x480 260nit PLC Modbus LCD Display With Case, DMG80480T043_A5WTC
This is a DWIN 4.3inch IPS, Capacitive Touch, RGB, IPS 800x480 260nit PLC Modbus LCD Display With Case, DMG80480T043_A5WTC. The Dwin 4.3inch Capacitive touch display comes with 16.7 millons RGB Colors with 260nit brightness, Which Based on T5L1, running DGUS II system, industrial grade.
Features
- T5L ASIC Industrial HMI, 16.7M Color, 24bit, 800*480 Pixel
- Resistive touch screen/Capacitive touch screen
- RS232&RS485 Interface,8Pin3.81mm Socket
- Easy-to-use DWIN DGUS V7.6 GUIs Development, no coding skills required
- Dual Development System: DGUS II/ TA(Instruction set)
- IPS View Angle: 85/85/85/85 (L/R/U/D)
- Connect with different PLC,Modbus protocal is supported
Specifications
Display
- Color : 16.7M（16777216） colors
- LCD Type : IPS
- Viewing Angle : Normal viewing angle, 85°/85°/85°/85° (L/R/U/D)
- Display Area（A.A）: 93.20mm (W) ×55.76mm (H)
- Resolution : 800x480
- Backlight : LED
- Brightness : DMG80480T043_A5WTC 260nit
Touch parameters
- Type : CTP (Capacitive touch panel)
- Structure : G+G structure with surface cover of Asahi tempered glass
- Touch Mode : Support point touch and drag
- Surface Hardness : 6H
- Light Transmittance : Over 90%
- Life : Over 1,000,000 times touch
Voltage & Current
- Power Voltage : 6~36V,typical value of 12V
- Operation Current : VCC = +12V, Backlight on,100mA / VCC = +12V, Backlight off,40mA
Reliability Test
- Working Temperature : -20~70℃
- Storage Temperature : -30~80℃
- Working Humidity : 10%~90%RH
- Conformal coating : Yes
Interface
- LCM interface : FPC40_0.5mm, RGB interface
- RTP interface : 5Pin_1.0mm interface
- Baud Rate : 3150~3225600bps
- Output Voltage : Output 1, Iout = 1mA;3.0~3.3 V / Output 0, Iout =-1mA;0~0.3 V
- Input Voltage（RXD : Input 1， Iin = 1mA；2.4~5.0V / Input 0， Iin = -1mA；0~0.5V
- Interface : UART2: N81,RS232 / UART4: N81,RS232 / UART5: RS485
- User interface : 8Pin_3.81mm socket for power supply and serial communication. Download rate(typical value): 12KByte/s
- FLASH : 16MBytes NOR Flash, for fonts, pictures and audio files. Rewrite cycle: over 100,000 times
- Speaker : Onboard speaker. Power: 2W
- SD interface : FAT32. Download files by SD interface can be displayed in statistics. Download rate: 4Mb/s
- PGT05 interface : When product crashes by accident, you can use PGT05 to update DGUS kernel and make the product return to normal
