Name: Ebyte E01-2G4M20S1B NRF24L01 PA+LNA 2.4GHz 20dBm Wireless Transceiver Module SMD
Brand: Ebyte
SKU: 06330
Price: 399.00 INR
Availability: OutOfStock

Ebyte E01-2G4M20S1B NRF24L01 PA+LNA 2.4GHz 20dBm Wireless Transceiver Module SMD

Ebyte

Ebyte E01-2G4M20S1B NRF24L01 PA+LNA 2.4GHz 20dBm Wireless Transceiver Module SMD

Based on 0 reviews. - Write a review

₹399.00

₹338.14 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 3
B2B GST Credit Available

Price in reward points: 339

Stock: 0 in Stock
SKU: 06330
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

Ebyte E01-2G4M20S1B NRF24L01 PA+LNA 2.4GHz 20dBm Wireless Transceiver Module SMD

E01-2G4M20S1B is a 2.4GHz SMD small-sized wireless module with PCB antenna developed by Ebyte. Built-in power amplifier (PA) and low-noise amplifier (LNA) on the original basis, so that the maximum transmit power reaches 100mW while receiving sensitivity is further improved.

Datasheet

Features

The maximum transmit power is 20dBm, which meets the battery power supply and greatly expands the communication distance
Communication distance can reach 1000m under ideal conditions
Global license-free ISM 2.4GHz band
Air data rate : 2Mbps, 1Mbps and 250kbps
125 communication channels to meet the needs of multi-point communication, packet, frequency hopping and other applications
Connect to MCU through SPI interface, the speed is 0 ～ 10Mbps
Professional RF shielding cover, anti-interference, anti-static
Industrial grade standard design for long-term use from -40 ～ + 85 ℃
Built-in PCB antenna, no need for external antenna

Specifications

IC: NRF24L01
Frequency: 2.4~2.525GHz
Power: 19~20dBm
Distance: 1000m
Communication interface: SPI
Antenna: PCB antenna
Operating temperature: -40 to +85℃
Package: SMD
Size: 23 * 14mm

Applications

Wearable devices
Smart home and industrial sensors
Security system, positioning system
Wireless remote control, drone
Wireless game remote control
Health care products
Wireless voice, wireless headphones
Automotive industry applications.
