Ebyte E01C-2G4M01S1B Si24R1 2.4GHz Wireless SoC Module SMD - SPI Interface - 200M Communication Distance

Ebyte E01C-2G4M01S1B Si24R1 2.4GHz Wireless SoC Module SMD - SPI Interface - 200M Communication Distance

E01C-2G4M01S1B is a 2.4GHz SMD wireless module with a small size and built-in PCB antenna based on Si24R1. It uses an industrial-grade high-precision 16MHz crystal oscillator. The module's RF performance and component selection are in accordance with industrial standards, and the product has obtained authoritative certification reports such as FCC, CE, and RoHS at home and abroad, so users do not need to worry about its performance. Since E01C-2G4M01S1B is a pure RF transceiver module, it needs to be driven by an MCU or a dedicated SPI debugging tool.

Datasheet

Features

• Communication distance is up to 200m
• The maximum transmit power is 5dBm (31mW), the software is adjustable for multiple levels
• Global license-free ISM 2.4GHz band
• Air data rate : 2Mbps, 1Mbps and 250kbps
• 125 communication channels to meet the needs of multi-point communication, packet, frequency hopping and other applications
• Connect to MCU through SPI interface, the speed is 0 ～ 10Mbps
• 2.0V ~ 3.6V power supply, ≥3.3V power supply can ensure the best performance
• Industrial-grade standard design, good for long-term use from -40 to 85°C
• PCB antenna
• Enhanced Shock Burst, fully compatible with all NORDIC nRF24L, nRF24E, nRF24U series
• Ultra-small size: 12 * 19mm

Specifications

• Chip solution: Si24R1
• Operating frequency: 2.4~2.525GHz
• Communication distance: 200m
• Communication interface: SPI
• Operating voltage: 2-3.6V
• Antenna interface: PCB antenna
• Working Temperature: -40 to +85℃
• Dimensions: 19*12mm

Applications

• Wearable devices
• Smart home and industrial sensors
• Security system, positioning system
• Wireless remote control, drone
• Wireless game remote control
• Healthcare products
• Wireless voice, wireless headphones
• Automotive industry applications
