Ebyte E01C-2G4M27D Si24R1 27dBm 2.4GHz SPI Wireless Serial Port Module - SMA-K Antenna Interface

The E01C-2G4M27D is a 2.4GHz DIP wireless module with a maximum transmit power of 500mW based on the domestic Si24R1.The module has built-in power amplifier (PA) and low-noise amplifier (LNA), which makes the maximum transmitting power reach 500mW, and the communication stability is greatly improved compared with the products. without power amplifier and low-noise amplifier, and the industrial-grade high-precision 16MHz crystal is used.

Datasheet

Features

Maximum transmitting power of 27dBm (about 500mW), adjustable at multiple software levels.
Communication distance up to 5km under ideal conditions.
Support for the global license-free ISM 2.4 GHz band.
Support for 2Mbps, 1Mbps and 250kbps air rates.
125 communication channels to meet the needs of multi-point communication, packet, frequency hopping and other applications.
Connection to MCU via SPI interface at 0 to 10Mbps.
Professional RF shield, anti-interference and anti-static.
Support 2.5 ~ 5.5V power supply, greater than 3.3V power supply can ensure the best performance.
4 fixing holes reserved for module welding and fixing.
SMA-K male threaded internal hole, can easily connect coaxial cable or external antenna The enhanced ShockBurst.
Enhanced ShockBurst, can interoperate with Nordic's nRF24L01+, nRF2401 and other 2.4G product series.

Specifications

IC: Si24R1
Frequency: 2.4~2.525GHz
Power: 27dBm
Distance: 5km
Communication interface: SPI
Antenna: SMA-K
Operating temperature: -40 to +85℃
Dimensions: 18*33.4mm
Package: DIP

Applications

Wearable device
Smart home and industrial sensors
Security system, positioning system
Wireless remote control, drone
Wireless game remote control
Healthcare products
Wireless voice, wireless headset
Automotive industry application
