Name: Ebyte E103-W02-DTU CC3200 2.4GHz 20dBm RS232/RS485 to WiFi Converter, Industrial WiFi Serial Server
Brand: Ebyte
SKU: 06288
Price: 3540.00 INR
Availability: InStock

Ebyte E103-W02-DTU CC3200 2.4GHz 20dBm RS232/RS485 to WiFi Converter, Industrial WiFi Serial Server

Ebyte

Ebyte E103-W02-DTU CC3200 2.4GHz 20dBm RS232/RS485 to WiFi Converter, Industrial WiFi Serial Server

This product qualifies for Free Surface Shipping !

All orders with value above 1999+GST are eligible for free delivery in Surface mode. (Not applicable for B2B offline orders)

Based on 0 reviews. - Write a review

₹3,540.00

₹3,000.00 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 30
B2B GST Credit Available

Price in reward points: 3000

Stock: 2 in Stock
SKU: 06288
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

Ebyte E103-W02-DTU CC3200 2.4GHz 20dBm RS232/RS485 to WiFi Converter, Industrial WiFi Serial Server

E103-W02-DTU is a transparent transmission serial port to WiFi server, which realizes two-way transparent transmission of RS232/RS485 serial port and WiFi data. It enables serial devices to immediately have TCP/IP network interface function, which greatly expands the communication distance of serial devices.

E103-W02-DTU is developed based on TI's CC3200 chip solution, and users can choose either RS232 or RS485serial port for communication. The serial server integrates the pass-through function, plug-and-play, supports serial AT command set, users can achieve the function of network access through the serial port, which is widely used in industrial automation, home security, instrumentation, intelligent home appliances, remote control, electric power and other fields.

E103-W02-DTU supports standard IEEE802.11b/g/n protocol and complete TCP/IP protocol stack, STA/AP working mode, Smart Config, serial port pass-through, power-on pass-through, etc. It is very convenient to realize network access function after simple configuration, which minimizes developers' work and project development time.

Datasheet

Features

Supporting standard RS232 interface
supporting standard RS485 interface
Support webpage configuration, you can access WiFi serial server through webpage and read or configure WiFi serial server parameters quickly
Supporting power-on pass-through, automatically connecting to WiFi network on power-on, and then connecting to the target device through the protocol
Support disconnection auto reconnect, after the network connection is disconnected and restored, the WiFi serial server will automatically reconnect to the target
Support remote AT command, WiFi serial server can be configured remotely using AT command
Support for OneNet, the IoT development platform
Industrial-grade design, supporting long-time operation at -40℃～+85℃
Efficient watchdog, which will restart automatically in case of abnormality.

Specifications

Frequency: 2.402~2.484GHz
Power: 20dBm
Communication Interface: RS232/RS485
WiFi version: 802.11 b/g/n
Test distance: 300 meter
Antenna type: SMA-K
Dimensions: 82 * 62 * 25 mm
