Ebyte E103-W12C-TB Ultra-low Power WiFi Module Test Kit

Ebyte E103-W12C-TB Ultra-low Power WiFi Module Test Kit

The E103-W12C-TB wireless module test kit is an entry-level development board for two serial port WiFi modules, using the E103-W12C module named for its ultra-low power consumption. This development board has complete Wi-Fi functions, and most of the module pins on the board have been led to pin headers on both sides. Developers can easily connect a variety of peripheral devices through jumpers according to actual needs, and can also Plug the development board into the breadboard and use it.

Datasheet

Specifications

• Support module: E103-W12C & E103-W12X
• Module size: 55* 38mm
• Power supply interface: Micro USB
• Communication interface: TTL
• Working temperature: -40 ~ +85℃
• Working humidity: 10% ~ 90%
• Storage temperature: -40 ~ +125℃
