Ebyte E108-GN03 AT6558R BDS/GPS/GLONASS GNSS Multi-mode Satellite Positioning And Navigation Module

The E108-GN03 series is a high-performance, highly integrated, low-power, low-cost multi-mode satellite positioning and navigation module based on the AT6558R solution, supporting BDS/GPS/GLONASS, with small size and low power consumption. It can be used in GNSS positioning applications such as vehicle navigation, smart wearables, and drones, and provides software and hardware interfaces compatible with other module manufacturers, greatly reducing the user's development cycle. It also supports multiple ways to connect to other peripherals, supports UART and GPIO interfaces, and if you need I2C and SPI interfaces, please contact customer service for customization.

Datasheet

Features

Support BDS/GPS/GLONASS multi-system joint positioning and single-system independent positioning
Support BeiDou B1I and B1C
The maximum positioning information update rate in single-system independent positioning mode can reach 25Hz
Support PPS output
Support A-GNSS service
Built-in reset controller
Support UART interface
With active antenna detection and protection
Output format: Support NMEA 4.11
High sensitivity: cold start -148dBm, hot start -159dBm, recapture -160dBm, tracking -167dBm
The software and hardware are compatible with those of other manufacturers, which greatly reduces the user's development time cycle

Specifications

Chip solution: AT6558R
Communication interface: UART/GPIO
Operating voltage: 2.7-3.6V
Communication protocol: NMEA0183 V4.1 and previous versions
Supported Positioning Systems: BDS/GPS/GLONASS
Communication interface: UART
Antenna Interface: stamp hole
Working Temperature: -40 to +85℃
Dimensions: 9.7*10.5*2.4mm

Applications

Vehicle positioning and navigation equipment
Wearable devices, such as GPS trackers
UAV positioning, industrial computers, etc.
Industrial equipment that requires GNSS positioning or navigation
Asset tracking
