Name: Ebyte E22-400M30S SX1268 433~470MHz 30dBm 12KM SPI Wireless LoRa Module
Brand: Ebyte
SKU: 06368
Price: 657.00 INR
Availability: OutOfStock

Ebyte E22-400M30S SX1268 433~470MHz 30dBm 12KM SPI Wireless LoRa Module

Ebyte

Ebyte E22-400M30S SX1268 433~470MHz 30dBm 12KM SPI Wireless LoRa Module

Based on 0 reviews. - Write a review

₹657.00

₹556.78 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 6
B2B GST Credit Available

Price in reward points: 557

Stock: 0 in Stock
SKU: 06368
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

Ebyte E22-400M30S SX1268 433~470MHz 30dBm 12KM SPI Wireless LoRa Module

The E22-400M30S is based on the SX1268, a new generation of LoRa TM RF chip manufactured by Semtech, USA. It is an ultra-small and self-developed 433MHz, 470MHz SMD LoRa TM wireless module.

Datasheet

Features

Communication distance tested is up to 12km
Maximum transmission power of 1W, software multi-level adjustable
Support the global license-free ISM 433MHz/470MHz band
Support air date rate of 0.018-62.5kbps in the LoRa TM mode
Support 300kpbs in the FSK mode
Compatible with the transceiver of SX1278/SX1276
With large capacity, FIFO supports 256Byte data cache.
New SF5 spreading factor to support dense networks
Support 2.5V~5.5V power supply, more than 5.0V power supply can guarantee the best performance
Industrial grade standard design, support -40 ~ 85 °C for working over a long time
IPEX and stamp hole are optional, which is convenient for secondary development and integration.

Specifications

IC: SX1268
Frequency: 410~493MHz
Power: 30dBm
Distance: 12km
Communication Interface: SPI
Antenna type: Stamp hole / IPEX
Operating temperature: -40 to +85℃
Operating humidity: 10 to 90%
Storage temperature: -40 to +125℃
Dimensions: 16 * 22.4 mm
Package: SMD

Applications

Home security alarm and remote keyless entry
Smart home and industrial sensors, etc.
wireless alarm security system
Building automation solutions
Wireless industrial-grade remote control
Advanced Meter Reading Architecture (AMI)
Applications in the automotive industry.
