Ebyte E22-400T33S UART 433~470MHz 33dBm LoRa Wireless Module

E22-400T33S is a wireless serial port module (UART) based on SEMTECH's LoRa solution, with an operating frequency of 410.125~493.125MHz (default 433.125MHz), TTL level output, and is compatible with 3.3V and 5V IO port voltages.

Datasheet

Features

Based on SEMTECH's high-performance RF chips, a new LoRa spread-spectrum modulation technology was developed, which brings a longer communication distance and stronger anti-interference ability.
It supports automatic relay networking, multi-level relay is suitable for ultra-long-distance communication, and multiple networks run in the same area at the same time
It supports users to set their own communication keys and cannot be read, which greatly improves the confidentiality of user data
Support LBT function, listen to the channel environmental noise before transmission, which can greatly improve the communication success rate of the module in harsh environments
Support RSSI signal strength indication function for evaluating signal quality, improving communication networks, and ranging
Support wireless parameter configuration, send command packets wirelessly, and remotely configure or read wireless module parameters
Supports wake-on-air, i.e., ultra-low-power function, suitable for battery-powered applications
Support fixed-point transmission, broadcast transmission, channel monitoring
It supports deep sleep, and the power consumption of the whole machine in this mode is about 2uA.
Support global license-free ISM 433MHz frequency band and support 470MHz meter reading frequency band
The module has built-in PA+LNA, and the communication distance can reach 16km under ideal conditions.
The parameters are saved after power-off, and the module will work according to the set parameters after re-powering
Efficient watchdog design, once an exception occurs, the module will automatically restart, and can continue to work according to the previous parameter settings
Support 2.4K~62.5kbps data transmission rate
Support 2.3~5.5V power supply, more than 3.3V power supply can ensure the best performance
Industrial-grade standard design, support long-term use at -40~+85°C
The maximum power of the module can reach 2W (33dBm), and the transmission is longer and more stable.

Specifications

Communication interface: UART
Communication distance: 16km
Carrier frequency: 410.125~493.125MHz
Transmit power: 33dBm
Product size: 25*40.5mm
Operating temperature: -40 to +85℃

Applications

Home security alarm and remote keyless entry
smart home and industrial sensors, etc.
wireless alarm security system
building automation solutions
Wireless industrial-grade remote control
healthcare products
Advanced Meter Reading Architecture (AMI)
Automotive applications.
