E220-400M22S LLCC68 410~493MHz 22dBm SPI SMD LoRa Wireless Module

E220-400M22S is an small module developed independently based on the generation of LoRa TM RF chip LLCC68 produced by Semtech company. LLCC68 is suitable for 433MHz and 470MHz SMD wireless module and uses industrial 32mhz crystal oscillator. Capable of operating in both 433MHz and 470MHz frequency bands, the E220-400M22S is a powerful yet compact wireless module, built with the reliable Semtech LLCC68 LoRa TM chip and a precision 32MHz crystal oscillator.

User Manual

Features

The measured distance can reach 5500m
The maximum transmitting power is 160mw, software is multi-level adjustable
Support global license free ISM 433 / 470MHz band
In LoRa TM mode, the data transmission rate is 1.76kbps ~ 62.5kbps
FSK mode supports up to 300kbps data transmission rate
FIFO has large capacity and supports 256 byte data cache
Support spread spectrum factor sF5, SF6, sf7, SF8, Sf9, SF10, SF11
Support 1.8V ~ 3.7V power supply, more than 3.3V power supply can guarantee the best performance
Industrial standard design, support - 40 ~ 85 ° C long-term use
Dual RF interface is optional (IPEX / stamp hole), which is convenient for secondary development and integration

Specifications

IC：LLCC68
Frequenc：410.125~493.125MHz
Power：22dBm
Distance：6km
Antenna type : IPEX / Stamp hole
Communication interface : SPI
Package : SMD
Size：20*14*2.8mm

Applications

Home security alarm and remote keyless entry
Smart home and industrial sensors, etc
Wireless alarm security system
Building automation solutions
Wireless industrial remote controller
Health care products
Advanced meter reading architecture (AMI)
Automotive industry applications
