Ebyte E32-900M30S SX1276 868/915MHz 30dBm 10Km SPI LoRa Wireless Module

Ebyte E32-900M30S SX1276 868/915MHz 30dBm 10Km SPI LoRa Wireless Module

E32-900M30s is a self-developed, 868/915MHz LoRa TM SMD wireless module with the maximum transmission power of 1W which is based on the SX1276 produced by Semtech in the United States.

Datasheet

Feature

• The measured communication distance can reach 10km
• Maximum transmission power of 1W, software multi-level adjustable
• Support 868/915 MHz band
• Support data transmission rate between 0.018K and 37.5Kbps in LoRaTM mode
• Support data transmission rate of up to 300kbps in FSK mode
• Support for multiple modulation mode, LoRa
• TM/FSK/GFSK/MSK/GMSK/OOK
• Large FIFO capacity, support 256Byte data cache
• Support 3.3V~5.5V power supply, power supply over 5 V can guarantee the best performance
• Industrial grade standard design, support -40 ~ 85 °C for working over a long time
• IPEX and stamp hole optional, good for secondary development and integration

Specifications

• Chip: SX1276
• Frequency: 850～931MHz
• Power: 30dBm
• Distance: 10km
• Communication interface: SPI

• Antenna: Sample hole / IPEX
• Size: 24*38.5mm
• Package: SMD




Applications

• Home security alarm and remote keyless entry
• Smart home and industrial sensors
• Wireless alarm security system
• Building automation solutions
• Wireless industrial-grade remote control
• Health care products
• Advanced Meter Reading Architecture(AMI)
• Automotive industry applications
