Quectel EC200U-EU C4-P01 Development Board Designed For QuecPython, Multi-Mode & Multi-Band Support, LTE Cat-1 / Bluetooth Communication, GNSS Positioning
The EC200U-EU C4-P01 development board is equipped with EC200U-EU LTE Cat 1 wireless communication module, with maximum data rate up to 10 Mbps downlink and 5 Mbps uplink, supports multi-mode & multi-band and is cost-effective. Designed in the compact and unified form factor, compatible with Quectel multi-mode LTE Standard EC20-CE. Onboard Type-C port for easy development with just a USB Type-C cable. Onboard 40PIN GPIO pin header which is compatible with most Raspberry Pi HATs.
User Manual / Datasheet / Example Codes Etc.
Features
- Equipped with EC200U-EU LTE Cat 1 wireless communication module, multi-mode & multi-band support.
- Onboard 40PIN GPIO header, compatible with most Raspberry Pi HATs.
- 5 LEDs for indicating module operating status.
- Supports TCP, UDP, PPP, NITZ, PING, FILE, MQTT, NTP, HTTP, HTTPS, SSL, FTP, FTPS, CMUX, MMS protocols, etc.
- Supports GNSS positioning (GPS, GLONASS, BDS, Galileo, QZSS).
- Onboard Nano SIM card slot and eSIM card slot, dual card single standby.
- Onboard MIPI connector for connecting MIPI screen and is fully compatible with Raspberry PI peripherals.
- Onboard camera connector, supports customized SPI cameras with a maximum of 300,000 pixels.
- Provides tools such as QPYcom, Thonny IDE plugin, and VSCode plugin, etc. for easy learning and development.
- Comes with online development resources and manual (example in QuecPython).
Specifications
- Model : EC200U-EU
- Antenna Connectors: LTE main antenna + DIV / WIFI (scanning only) / Bluetooth antenna + GNSS antenna
- Operating Temperature: -30 ~ 75°C
- Storage Temperature: -45 ~ 90°C
FREQUENCY BAND
- LTE-FDD: B1, B3, B5, B7, B8, B20, B28
- LTE-TDD: B38, B40, B41
- GSM / GPRS / EDGE: GSM: B2, B3, B5, B8
- GNSS: GPS, GLONASS, BDS, Galileo, QZSS
Bluetooth: Bluetooth 4.2 (BR/EDR) - Wi-Fi Scan: 2.4 GHz 11b (Rx)
DATA TRANSMISSION
- CAT 1: LTE-FDD: DL 10 Mbps; UL 5 Mbps, LTE-TDD: DL 8.96 Mbps; UL 3.1 Mbps
- NB-IoT: N/A
- Cat-M: N/A
- GSM / GPRS / EDGE: GSM: DL 85.6 Kbps; UL 85.6 Kbps
- Type-C USB Port: Supports AT commands testing, GNSS positioning, firmware upgrading, etc.
- Communication Protocol: TCP, UDP, PPP, NITZ, PING, FILE, MQTT, NTP, HTTP, HTTPS, SSL, FTP, FTPS, CMUX, MMS
- SIM Card: Nano SIM and eSIM, dual card single standby
- P01: Module Pin 1, default as EC200A-XX PWM0
- P05: Module Pin 5, NET_MODE indicator
- SCK1: SIM1 detection indicator, lights up when SIM1 card is inserted
- SCK2: SIM2 detection indicator, lights up when SIM2 card is inserted
- PWR: Power indicator
Buttons
- PWK: Power ON/OFF
- RST: Reset
- BOOT: Forcing into firmware burning mode
- USB ON/OFF: USB power consumption detection switch
Package Includes
Onboard 40PIN GPIO Header
Compatible With Most Raspberry Pi HATs
What’s Onboard
