Ebyte ECAN-S01 Can2.0 to Serial TTL Protocol Converter Module, Support 5 Working Modes
ECAN-S01 is a small intelligent protocol conversion module developed by Chengdu Ebyte Electronic Technology Co., Ltd. The product enables bidirectional conversion between CANand TTL data in different protocols. The product supports serial AT command configuration and host computer configuration device parameters and operating modes, There are five data conversion modes, including transparent conversion, transparent ribbon identity conversion, protocol transformation, Modbus RTU transformation, and custom protocol transformation (user). At the same time, the ECAN-S01 intelligent protocol converter has the characteristics of small size and easy installation, which has a high cost performance in CAN-BUS product development and data analysis applications, and is a reliable assistant for engineering applications, project debugging and product development
Features
- Bidirectional conversion between CAN and TTL is supported.
- Supports Transparent Conversion, Ribbon Identity Conversion, Protocol Transformation, CustomProtocol Transformation.
- Supports Modbus RTU conversion
- Support TTL interface, AT instruction, host computer parameter configuration.
- Supports hardware restore
Specifications
- voltage : 2.3V~5.5V
- Working current : Standby current: 17.5mA@5V TX current: 20mA@5V
- Operating temperature : -40℃~85℃, industrial grade
- Communication level : 3.3V, if connected to 5V, level conversion is required
- Working humidity : 10%~90%, relative humidity, non-condensing
- Serial port baud rate : 115200 bps
- Parity check : None
- Data bit : 8
- Stop bit : 1
- Flow Control : close
- CAN baud rate : 100K bps
- CAN ID : 0x00000000
- Transparent transmission mode : Receive all data types
