Ebyte ECM50-A07 Programmable Industrial Grade Computer - Based ESP32-S3R8 Dual-core 240MHz Processor - Support RS485, LoRa, Wi-Fi & BLE

The ECM50-A07 is a full-scenario communication industrial-grade programmable industrial control computer based on the ESP32-S3 chip. It supports four communication methods: Wi-Fi, Bluetooth, Ethernet, 4G, and LoRa, and multiple network protocols such as TCP, HTTP, and MQTT. Users can program using the MicroPython language to execute customized business logic and data processing on the industrial control computer. It is suitable for various IoT data acquisition, transmission, and control scenarios, and users can quickly develop their own business functions using the rich sample source code provided by the official website. This greatly reduces the development cycle and saves project development costs.

Datasheet

Specifications

Processor Model: ESP32-S3R8
Clock speed: Dual-core 32-bit LX7 microprocessor, with a maximum clock speed of 240 MHz.
Memory: 8MB PSRAM
Storage: 16MB NOR FLASH
Extended storage : 1* TF card slot
RS485/RS232: RS485
LoRa: Data transmission rate up to 62.5Kbps over a communication distance of 5km (under ideal conditions). Operating frequency band: 410.125~493.125MHz
Ethernet interface: 1* RJ45 10/100Mbps
WiFi: WiFi supports IEEE 802.11b/g/n; it supports 20MHz and 40MHz bandwidth in the 2.4GHz band, supports 1T1R mode, and has a data rate of up to 150Mbps.
Bluetooth: Bluetooth Low Energy (Bluetooth LE): Bluetooth 5, Bluetooth mesh
FROM: 2* Digital signal detection, compatible with both dry and wet contacts; wet contacts default to NPN type.
AI: 2* Analog signal detection, default current type 4-20mA; voltage type can be changed; 12-bit accuracy.
DO: 2 relays, 3A 250VAC
Button: 1* Reset button
Indicator lights: Power indicator, operation indicator (programmable), Ethernet indicator, WiFi indicator (programmable), 4G/LoRa indicator
Power input: DC 8-28V Phoenix terminal interface or DC 5V Type-C interface
Power consumption: Typical value: 0.W (RF fully open), Relay fully open: 1.56W
Operating temperature: -40℃ ~ 85℃;
Storage temperature: -40℃ ~ 85℃
Operating humidity: 5~95% humidity, non-condensing
Storage humidity: 60℃@95% humidity, non-condensing
Dimensions: 111.2*79.2*28mm (excluding terminals and lugs)

Applications

Intelligent instruments, smart gas and water meters, and automated control
Industrial data collection, smart factories, and assembly line automation transformation
Assisted vending equipment, low-power collection, and smart fire protection
Smart agriculture, smart water services, smart parking, and smart scenic spots
Outdoor testing, water conservancy and geological testing, hydrology and water conservancy
Smart environmental protection, energy collection, smart animal husbandry, smart meteorology
Power distribution management, smart street lights

Package Includes

1x Ebyte ECM50-A07 Programmable Industrial Grade Computer
